RAP Screening and crushing plant

The Recycling Granulator gently granulates the material, does not break the structure of the original aggregate, and produces virtually no fines and dust. It can provide ideal conditions for adding recycled asphalt material (RAP) to the asphalt mixing plant.

Capacity: 60T-120T/H

Delivery: 30 days

Warranty: 13 months

Equipment highlights: Fully automatic operation, frame structure and advanced technology

  • Recommended reason
  • Technical highlights
  • Prodcts parameters
  • Equipment advantages
  • Engineering example
  • Online Message
Recommended reason


Technical highlights

1. The single roll crusher adopts the protective plate made of wear-resistant material to protect the standard cutter head, which has strong crushing ability, good wear resistance, convenient replacement and prolongs the service life of the equipment.;

2. Low speed spindle can effectively reduce dust emission;

3. Floating twin-roll crushing can effectively prevent large RAP material from causing instantaneous equipment failure;

4. Interlaced wear-resistant tooth plate, effective crushing of RAP without sticking;

5. High frequency vibrating screen combined with anti-blocking screen technology can effectively solve the problem of fine aggregate adhering screen.
Prodcts parameters
Model R60 R100
Production Capacity 60t/h 100t/h
Total Power 74KW 120KW
Dimensions 28mx12mx5m 28mx12mx5m
Discharge Particle Size 0~35mm (adjustable) 0~35mm (adjustable)
Loading Height 3300mm 3300mm
Feed Width 3500mm 3500mm
Capacity 10m3 14m3
Screening Machine Double layer Screening Machine Double layer Screening Machine
Secondary Grain Machine (double shaft) 2PG60 2PG80
